Road Dump Trailers

                          Model

AM 480-285

AM 510-700

AM 610-1000

AM
612-1200

AM
614-1400

AM
616-1400

AM
616-2000

Weight approx lbs

1350

1865

1925

2350

2650

3 100

3400

GVWR  Ib

2850

7 000

10000

12000

14000

14000

20000

Capacity (pi3)

53

83

100

120

140

160

160

Loading surface

50″ x 97″

60″ x120″

72″ x120″

72″ x 142”

72″ x 168″

72″ x1 92″

72″ x 192″

Overall Lenght

147″

172 1/2″

172 1/2″

197″

221 “

245″

245″

Overall Width

70″

82 1/2″

94 1/2″

94 1/2″

94 1/2″

94 1/2″

94 1/2″

Coupler Height

13″

15″

15″

15″

20″

20″

20″

Sides height

20″

20″

20″

20″

20″

20″

20″

Track width
c to c

60″

72″

84″

84″

84″

84″

84″

Axle diameter

1.900″(2)

2 3/8″(2)

3″(2)

3″(2)

3″ (2)

3″ (2)

3″ (3)

Bolts qty

5

5

6

8

8

8

8

Suspension (spring)

Std

Std

Std

Std

Std

Std

Std

Tire

175/80Dl3

225/75Dl5

225/75Dl5

235/85R16

235/85R16

235/85R16

235/85R16

Tailgate

Double doors

Coupler

2″

2 5/16″

2 5/16″

2 5/16″

2 5/16″

2 5/16″

2 5/16″

12 volts hydUnit

(only included bundled with dumper alone) dumper

Inc

Inc.

Inc.

Inc.

Inc.

Inc.

Inc.

Electric brake

Opt 7″

Inc 10″

Inc 12″

Inc 12″

Inc 12″

Inc 12″

Inc 12″

Cylinder

Under
3″ x 16″(I)

Under
3″ x I6″(2)

Under
3″ x16″(2)

Télescopic

Télescopic

Télescopic

Télescopic

MODEL                            DESCRIPTION                                AXLES
AM 480-285               4' X 8' Hydraulic Dump Trailer         2 Axles of 1,500 lbs
AM 510-700             5' X 10' Hydraulic Dump Trailer         2 Axles of 3,500 lbs
AM 610-1000           6' X 10' Hydraulic Dump Trailer         2 Axles of 5,000 lbs
AM 612-1200           6' X 12' Hydraulic Dump Trailer         2 Axles of 6,000 lbs
AM 614-1400           6' X 14' Hydraulic Dump Trailer         2 Axles of 7,000 lbs
AM 614-1600           6' X 14' Hydraulic Dump Trailer         2 Axles of 8,000 lbs
AM 616-1400           6' X 16' Hydraulic Dump Trailer         2 Axles of 7,000 lbs
AM 616-2000 *        6' X 16' Hydraulic Dump Trailer         3 Axles of 7,000 lbs
